R I D G E
OVERDRIVE
Tax included. Outside the EU, customs duties may apply.
Tax included. Outside the EU, customs duties may apply.
Shipping calculated at checkout.
SPECIFICATIONS
INPUT IMPEDANCE: 1Meg Ohm (Guitar mode) / 32k Ohm (Line mode)
OUTPUT IMPEDANCE: 100 Ohm
BYPASS SWITCHING: True Bypass (electromechanical relay switching)
DIMENSIONS: 11.2 cm deep x 16.4 cm wide x 5.2 cm tall (4.4 inches deep x 6.5 inches wide x 2 inches tall).
WEIGHT: 850 g (1,8 lbs)
BUILD MATERIAL: 5mm thick aluminium casing with summit white smooth and high grade painting surface
CAPABILITIES: Designed for both guitar, bass, synth and studio.
MIDI CABLE REQUIREMENTS: Use a type A mini jack TRS MIDI cable.
POWER ADAPTOR REQUIREMENTS: Use an adaptor (not included) with the following rating: 9VDC center negative. (250mA minimum, 300mA or more recommended.)
FEATURES
RIDGE MOOD
Kernom's distinctive MOOD knob enables you to explore a limitless array of overdrive clipping variations. Whether you prefer soft or hard clipping, symmetrical or asymmetrical characteristics, inspired by Germanium or Silicon diode behavior, our Augmented Analog circuitry empowers you to embark on a sonic voyage spanning the full spectrum of drive tones. With just a single twist of the knob, you can seamlessly transition from an ultra-clean boost to ferocious high-gain intensity, passing through dynamic overdrive or more compressed textures.
Advanced EQ section to sculpt your ideal tone.
To begin, we offer the traditional POST-TONE control positioned after the clipping stage, allowing you to fine-tune how your pedal interacts with your amplifier, in an advanced version within the RIDGE. Recognizing the substantial impact that guitar interaction can have on overdrive tone, we've introduced a distinctive PRE-TONE adjustment before the clipping stage. This feature lets you modify how your playing influences the dynamics of the overdrive tone. Additionally, we've included a MID section to help your sound either stand out or seamlessly blend with other instruments in a mix.
Connect your expression pedal to the RIDGE to control any combination of knobs and explore new possibilities.
Use the internal preset accessible via the dedicated footswitch to have access to two sounds at any given time.
Full MIDI compatibility with easy editing features. Save and recall up to 128 different presets.
OVERVIEW
MID
Highly responsive MID Eq to shape the way your sound sits in the mix.
MOOD
Mood continuous control to choose from an infinite number of different clipping flavors.
VOLUME
Output volume control. Up to 30V output voltage from standard 9V input for ultimate dynamics to punish your amp using the VOLUME knob.
DRIVE
From ultra clean boost to full overdriven high gain Drive.
POST TONE
Post tone acting after the clipping stage to precisely tailor your output sound, from fat and heavy to beautiful chime.
PRE TONE
Pre tone acting before the clipping stage to change the way the pedal reacts to your guitar.
PRESET
1 onboard preset, 128 presets accessible via MIDI.
True bypass with relay.
Expression pedal Input.
MIDI in and OUT with full control OVER all the parameters.
SASHA IVANTIC
"What the F*** ?! I knew this could match standard pedals but never expected it could do like a stacked combination of pedals. I think the RIDGE is going to be with me for a very long time."
LIVINGROOM
"There are no tradeoffs, no compromises with sound despite the functionality and the versatility (...)"
RIFFS BEARDS & GEAR
"The MOOD knob is where all the craziness happens", "This pedal is pretty wild, real talk"
WATCH MORE
Check out our YouTube playlist for a compilation of all the videos about us.
SASHA IVANTIC
"What the F*** ?! I knew this could match standard pedals but never expected it could do like a stacked combination of pedals. I think the RIDGE is going to be with me for a very long time."
J
I got my Ridge from a dealership in Thailand recently and had my first gig with it, kinda a deep dive , the pedal sounds great but tweaking and saving a midi preset in a live situation is a struggle (to many steps), apparently my model is an earlier model (although its brand new), however, the user manual clearly explains how to save midi presets (8A and 8B) but the functionality is lacking, bummer.
Z
Du clean boost à la fuzz, cette pédale fait tout !
Je l’utilise avec une Midi mouse ou une Hotone Ampero control pour les changements de patch, il y a zéro latence.
J’ai eu l’occasion de tester le SAV de Kernom suite à un petit bug de la pédale, ils sont très réactifs et aimables.
S
The Ridge is a beautiful drive that can have a ton of different flavors. The MOOD control is absolute genius. The pedal is able to achieve the greatest guitar tones ever produced. Absolutely incredible.
J
The Kernom Ridge is the best distortion pedal I have ever used. Mine did have a rare issue with some circuitry. Kernom paid for shipping out of the US, fixed it, and shipped it back...no questions asked. They were quick, cordial, and I didn't pay a dime. customer for life!
D
An analog circuit with the advantages of Midi - ingenious. The pedal really does always sound great. No matter how the controls are set. Apart from the Mood control, I love the Mid control - really super musical and effective. My favorite setting is kind of a boost setting, with a bit of a clone like EQ curve, I guess. Fantastic piece of gear. I'm really excited about the new Fuzz coming out.
